Magnetic Rubber Chamfer

Magnetic Rubber Chamfer

Magnetic rubber chamfer strip is a rubber-based product used to provide an even, smooth surface around the edges of precast concrete components. The rubber-magnetic chamfer strip helps ensure tight connections between the different elements and provides better protection against weathering and abrasion. This rubber material also helps reduce noise and vibration, which makes precast concrete projects more comfortable for people. This rubber strip is available in different sizes and shapes depending on the needs of the project, making it a versatile material for any application.

Description

Magnetic Rubber Chamfer

The “rubber magnetic chamfer strip” is a type of precast concrete accessory used to create chamfered edges on concrete structures. It is made of a rubber material and has a magnetic strip embedded in it. The rubber material provides flexibility and durability, while the magnetic strip helps the strip to stick to the concrete surface and stay in place during installation. The chamfer strip is used to create a 45-degree angled edge on the concrete structure, which can enhance the aesthetic appearance of the structure and provide additional protection against chipping and cracking of the edges. The rubber-magnetic chamfer strip helps ensure tight connections between the different elements and provides better protection against weathering and abrasion. TThis rubber strip is available in different sizes and shapes depending on the needs of the project, making it a versatile material for any application. It also provides improved strength and durability to the edges of precast concrete components.

rubber magnetic chamfer strip
rubber magnetic chamfer strip

Feature of Magnetic Rubber Chamfer

Easy to install:

Rubber magnetic chamfer strips are easy to install . They can be quickly placed in position, secured with the embedded magnets, and then held in place until the concrete sets.

Durable and long-lasting:

The rubber material used in the chamfer strip is highly durable and can withstand harsh weather conditions, UV radiation, and other environmental factors that can damage other types of chamfer strips. Rubber magnetic chamfer strips can also be reused multiple times, making them a cost-effective and sustainable solution.

Enhances aesthetics:

Chamfered edges create a sleek, modern look for concrete structures, and rubber magnetic chamfer strips can help achieve this look easily and affordably.

Provides protection:

Chamfered edges can help protect the concrete structure from chipping and cracking. The rubber material used in the chamfer strip can also help absorb impact and reduce the likelihood of damage to the concrete.

Versatile:

Rubber magnetic chamfer strips can be used in a wide range of construction projects, including both residential and commercial applications. They are also compatible with different types of concrete and can be used with precast or cast-in-place concrete.

How to choose single-sided or double-sided magnetic chamfer?

1. Single-sided magnetized : Suitable for use when attached to one steel surface at a time, such as a steel table or a steel panel
2. Double-sided magnetized : Used in two adjacent steel

Rubber magnetic chamfers are available in 5x5mm, 8x8mm, 10x10mm, 15x15mm. Of course, if you have special requirements, please contact us and send us the drawings.

Rubber magnet chamfer drawing picture
rubber magnet chamfer drawing picture

Package of Magnetic Rubber Chamfer

Packing: 125 meters per carton,

Delivery Date: 7-10 days

The packaging of each product is reviewed by professional testing and packaging personnel. After passing the review, the box is sealed and shipped. We cooperate with professional international logistics/freight forwarders to ensure that the products you receive are perfect and undamaged.









Specification

Triangle magnetic rubber chamfer strip:

Product No.
L
W
C
MAG-5X5 5 5 7
MAG-8X8 8 8 11
MAG-10X10 10 10 14
MAG-15X15 15 15 21
MAG-20X20 20 20 28

Trapezoidal magnetic rubber chamfer strip:

Product No.
T
t
h
MAG-40x20x10 40 20 10
Type 2

Product No.
T
t
h
MAG-60x400x20 60 40 20
MAG-140X120X20 140 120 20

ASK FOR A QUOTE

We are not just providing simple quotes but experts in selection, calculation, and drawing.
